Safe Water Buoy / Floating Marker Buoys / Marine Navigation Buoys
►Company introduction
Qingdao Henger Shipping Supplies Co., Ltd
Lies in Qingdao, a beautiful coastal city with red tiling and green
trees, blue sea and clear sky, Qingdao Henger Shipping Supplies
Co., Ltd is a high-tech enterprise integrated with manufacturing,
research and innovation, technical services, specialized in
manufacturing marine products, such as marine rubber fender, marine
airbag, navigation mark and marine buoy. All products get ISO
9001-2008 certificate and IACS quality authentication from CCS, BV,
GL, ABS, LG, etc. With strong technology base, advanced
manufacturing technique, complete manufacturing facilities and
well-equipped checkout equipment, Qingdao Henger Marine Supplies
Co., Ltd is devoted to forge itself into a top-ranking
international competitive marine products manufacturer providing
high quality products and perfect service for all customers, and
shoulder the responsibility of ensuring global marine safety via
mutually beneficial cooperation with friends all over the world.
►Marine Navigation Buoys Parameter
| Type | Body Diameter(mm) | Height (mm) | Lantern Suppport Height(mm) | Local Height (mm) | Lantern | Draft(mm) | Water Depth(mm) |
| HF1.5-D1 | 1500 | 5300 | 1800 | 2600 | LED155 | 1150 | 3.5-15 |
| HF1.8-D1 | 1800 | 5240 | 2350 | 2900 | LED155 | 2100 | 6-15 |
| HF2.4-D1 | 2400 | 7780 | 3040 | 4150 | LED155 | 3830 | 13-40 |
| HF3.0-D1 | 3000 | 7980 | 3450 | 4600 | LED155 | 3480 | 13-40 |
| HF1.5-D2 | 1500 | 3204 | 1270 | 1620 | LED155 | 1100 | <2 |
| HF1.8-D2 | 1800 | 4270 | 2340 | 2940 | LED155 | 1330 | <10 |
| HF2.4-D2 | 2400 | 5700 | 3040 | 3980 | LED155 | 1720 | <30 |
►Marine Navigation Buoys Introductions
HIGH QUALITY MATERIALS
Lifting and mooring points: SS304 stainless steel
Float and mast: High density UV-stabilized polyethylene
Eco friendly: Recyclable polyethylene. No heavy metals. No
ecological damages.
HIGH ADDED VALUE DESIGN
Weight: Up to 3 times lighter than steel buoys of equal size.
Shape: The design of our floats is studied to provide maximum
stability.
Assembly and use: Thanks to the lightness and modularity, the
assembly and maintenance of floats are easy.
The construction also includes two lifting eyes and molded handles.
QUALITY MANUFACTURES
Designed and made in China
Stability of floats: Our polyethylene floats are built to guarantee
an excellent buoyancy and remain unsinkable.
High visibility: Pigments matching IALA specifications are directly
integrated into the polyethylene. No painting required.
Shock resistance: Our entire range of polyethylene floats
guarantees an excellent resistance to impacts. Polyethylene is a
shape-memory polymer (after a violent shock, our floats recover
their initial shapes).
Tension: Our floats are also developed to ensure a strong pull out
resistance.
COST SAVING
Price:Lowest prices on the market without lowering the quality, safety
and performances of our marine buoys. |
High Life Expectancy: Compared to steel buoys, plastic buoys will not corrode and our
floats are designed for a long-lasting activity. |
Service and Maintenance: UV-stabilized polyethylene limits marine growth and enables an easy
and fast cleaning "on board". Large intervals between servicing
result in major costs savings. No painting needed. Lifting and mooring points can be replaced easily and within a few
minutes. Float and mast can also be repaired in case of damage. |
Transport: Our modular design optimizes container loading and makes the fret
easier and cheaper. |
►Pneumatic rubber fender service
| Quality is the cornerstone, service is the soul. We continue to
provide our customers with stable & reliable quality pneumatic
rubber fenders with a comprehensive system of technical support,
meticulous and thoughtful after-sales service to win customers
trust and satisfaction. Qingdao Henger Shipping Supplies Co., Ltd
provides following services to all customers. |
| 1. 24 hours instant online technical consultation and support. |
| 2. 24 months warranty period(without any artificial damage) and
free repairing service within warranty period. |
| 3. lifetime reparing service. |
