High Quality 100% UHMWPE Marine Mooring&Towing Rope For Ship

Mooring Rope Introduction

Multiple strands of rope used to tie ships. Requires tensile, impact, abrasion resistance, flexibility and softness. In the past, steel cables, linen or cotton ropes were commonly used; after the emergence of synthetic fibers, most of them were made of nylon, polypropylene, vinylon, polyester, etc. In addition to light weight, high strength, good impact resistance and abrasion resistance, synthetic fiber ropes have the advantages of corrosion resistance, mildew resistance, and insect resistance. For example, the strength and abrasion fastness of nylon ropes are several times higher than hemp and cotton ropes, and the specific gravity of polypropylene ropes is less than water, which can float on the water and is easy and safe to operate. Chemical fiber cable is divided into 3 strands, multi-strand twisted cable and 8-strand, multi-strand twisted cable according to the processing structure. The 3-strand cable is generally 4-50 mm in diameter, and the 8-strand cable is generally 35-120 mm in diameter. In addition to chemical fiber ropes, they are also widely used in transportation, industry, mining, sports and fishery. According to the needs of special applications, metal materials can also be incorporated into the cable core.

Polymer Polyethylene Rope
DIA		CIR	WT		B/S
MM	INCH	INCH	KGS/100M	LBS/100FT	TON	KN
6	1/4	3/4	2.3	1.5	4.3	42
8	5/16	1	3.7	2.5	6.7	66
10	13/32	1-1/4	5.6	3.7	9.7	95
12	15/32	1-1/2	7.9	5.3	13.3	131
14	9/16	1-3/4	10.6	7.1	17.8	174
16	5/8	2	13.7	9.2	22.9	225
18	23/32	2-1/4	17.3	11.6	28.8	282
20	13/16	2-1/2	21.2	14.3	35.3	346
22	7/8	2-3/4	25.6	17.2	42.5	416
24	15/16	3	30.4	20.4	50.3	493
26	1-1/32	3-1/4	35.7	24.0	58.8	576
28	1-1/8	3-1/2	41.3	27.8	67.8	665
30	1-3/16	3-3/4	47.4	31.8	77.5	760
32	1-1/4	4	53.9	36.2	87.8	860
34	1-11/32	4-1/4	60.8	40.8	98.6	966
36	1-7/16	4-1/2	68.1	45.8	110	1078
38	1-1/2	4-3/4	75.9	51.0	122	1196
40	1-19/32	5	84.0	56.5	135	1318
42	1-21/32	5-1/4	92.6	62.2	148	1447
44	1-3/4	5-1/2	102	68.3	161	1581
46	1-13/16	5-5/8	111	74.6	176	1720
48	1-7/8	6	121	81.3	190	1864
50	2	6-1/4	131	88.0	205	2013
52	2-1/16	6-1/2	142	95.3	221	2167
56	2-1/4	7	164	111	254	2490
60	2-3/8	7-1/2	189	127	289	2831
64	2-1/2	8	215	144	326	3191
68	2-11/16	8-1/2	242	163	364	3567
72	2-7/8	9	271	182	404	3961
80	3-5/32	10	335	225	488	4787
88	3-7/16	11	405	272	578	5669
96	3-13/16	12	481	324	673	6599
Other sizes available upon request

Mooring Rope Application

Company Introduction

Our company mainly produces polypropylene (polypropylene), nylon (polyamide), polyester (polyester), polyester-acrylic hybrid, nylon, ultra-high molecular weight polyethylene series cable, Product diameter: 4mm~120mm, optional .The structure has 3 strands, 4 strands, 6 strands, 8 strands, 12 strands, and a double-woven 24-strand, 32-strand, 36-strand rope of various structural types.

The company's products have the characteristics of high strength, low elongation, anti-wear and anti-corrosion, and the performance indicators are in line with relevant national standards and international standards. Nowadays, the products have been widely used in deep sea mooring, marine engineering, ocean transportation, national defense military, port towing, water conservancy engineering and special equipment.

Qingdao Henger Marine Supplies Co., Ltd is a high-tech enterprise integrated with manufacturing, research and innovation, technical services, specialized in manufacturing marine products, such as Yokohama Fender, marine rubber fender, marine airbag, navigation mark and marine buoy. All products get ISO 9001-2008 certificate and IACS quality authentication from CCS, BV, GL, ABS, LG, etc.

With strong technology base, advanced manufacturing technique, complete manufacturing facilities and well-equipped checkout equipment, Qingdao Henger Marine Supplies Co., Ltd is devoted to forge itself into a top-ranking international competitive marine products manufacturer providing high quality products and perfect service for all customers, and shoulder the responsibility of ensuring global marine safety via mutually beneficial cooperation with partners from all over the world.
